Product Details
Customization: | Available |
Type: | Normal Pressure Transmitter |
Structure Type: | Diffused Silicon Pressure Transmitter |
Product Description
| Model NO. | PMC51/PMC51B/PMP51/PMP51B/PMC41/ PMC45 |
| Accuracy Grade | 0.2G |
| Pressure range | 0.001MPa～35MPa |
| IP Rating | IP68 |
| Certification | CE |
| Customized | Customized |
| Process Temperature | -20°c...130°c |
| Main Wetted Parts | Ceraphire Sealing Alloy C276 316L |
| Max. Measurement Distance | 400 M H2O |
| Measuring Cell | 100 Mbar...40 Bar |
| Material Process Membrane | Ceramic |
| Transport Package | Carton |
| Specification | 0.001-40Mpa |
| Trademark | Endress+Hauser |
| Origin | Europe or China |
| HS Code | 9026201090 |
| Production Capacity | 50000/Year |
| Packaging & Delivery | |
| Package Size | 30.00cm * 26.00cm * 24.00cm |
| Package Gross Weight | 20.000kg |
Field of Application:
The Cerabar digital pressure transmitter with capacitive, oil-free ceramic measuring cell is ideal for process and hygienic applications, providing accurate pressure, level, volume, or mass measurements in liquids and gases. It ensures system safety with a vacuum-proof ceramic membrane featuring integrated breakage detection.
Features:
● Single chamber aluminum or stainless steel (316L) housing
● Process connections: Threads, flanges, or hygienic connections
● Process temperature: -40 to +130°C (-40 to +266°F), 150°C (302°F) for 1h
● Measuring ranges: -1/0 up to +40bar (-15/0 to +600psi)
● Accuracy: ±0.1%, "Platinum" ±0.075%
● International explosion protection certificates, SIL, hygienic approvals, marine approvals
Benefits:
● Suitable for vacuum applications and corrosive/abrasive media
● Membrane breakage detection for process safety
● Overload-resistant high purity ceramic sensor (99.9% Al2O3)
● Condensation resistant for hygienic applications
● Easy menu-guided commissioning via local display, 4 to 20mA with HART, PROFIBUS PA, FOUNDATION Fieldbus
● Process pressure up to SIL2, certified to IEC 61508 and IEC 61511
● Available with mounted manifolds for easy installation and leak testing
For more product information, please log in: https://technoxm.en.made-in-china.com
Welcome to send an email to inquire about the specific required model of product.
E-Mail：sales@tech-xm.com
